Azure 1/3 - 1/2 HP ECM Direct Drive

Azure 1/3 - 1/2 HP ECM Direct Drive

$303.35
In stock: 5 available
Product Details
Brand: MARS

AZURE 1/3 - 1/2HP ECM D/D

Motor Type ECM Enclosure OAO HP (Max.) 1/2 Voltage 120/240 Mounting Belly Band Speeds 5 Hz 60/50 Rotation REV+FWD Multi-Rated HP 1/3-1/2 RPM Range Constant Torque NEMA Frame Size 48 Phase Single Standards CUL FLA 6.4/3.8 Bearing Ball Lead Length (in.) 15.75 Thermal Protection REDUNDANT Electronic Control CIRCUITS Ambient Deg C 55 Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 4.94 Replaces All Standard PSC motor Duty Continuous
Item #: 10865

Azure ECM Direct Drive PSC

Azure connects directly to OEM harnessesBall bearing, Thermal Overload ProtectionMulti-HP Dual Voltage4 speeds plus 625 RPM constant fan modeAirflow Adjustment - 08502 Hand Held ProgrammerHigh efficiency 85%Ultimate Truck StockReplaces All PSC Motors
Show More
