Azure 1/8 - 1/3 HP Condenser Fan Motor
$199.87
In stock: 4 available
Product Details
Brand: MARS
Motor Type ECM Enclosure CAO HP (Max.) 1/3 Voltage 230 Mounting Stud Speeds 1 Hz 60/50 Rotation CW/CCW Multi-Rated HP 1/8 - 1/3 RPM Range 825/1075 NEMA Frame Size 48 Phase Single Standards UR FLA Proprietary Bearing Ball Lead Length (in.) 33 Thermal Protection Electronical Protection Ambient Deg C -32C-+55C NOTE Shaft down only mounting. Remove the drain plugs a Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 6.5 Duty Continuous
Azure ECM Condenser Fan
- Replaces a Multitude of PSC Motors
- No capacitor is required
- Multi horsepower, self-adjusting 825/1075 RPM,
- Ball Bearing Reversible Rotation Water Slinger on shaft
- High efficiency ECM Outboard surge protection included w/wiring harness
